Name: Roof Batten / Z-Purlin (Light Gauge GI, Tile or Sheet Support)
Brand: ttkbuildingmaterials.com Product Index
Availability: InStock

WHAT IT IS

Roof batten / Z-purlin in light-gauge GI is a cold-formed galvanised steel secondary member that runs horizontally across C-purlins to provide the direct fixing surface for clay tiles, fibre cement tiles, or corrugated metal sheeting in Malaysian roof construction. Standard length is 6 m; profile dimensions are 35 mm × 60 mm or 63 mm × 26 mm × 32 mm; steel thickness is typically 0.45–0.47 mm GI. The Z-section interlocks with adjacent lengths for continuous span runs. Battens are fixed at gauge intervals matching the tile head lap, with roofing screws driven directly through. HS 7210619200 · import duty 15% · SST 5%. Lightweight design reduces overall roof dead load, important for long-span lightweight steel truss systems widely used in Malaysia.

UNIT OF MEASURE

LENGTH (PRIMARY) M KG

Typical pack size: Standard length 6 m; profile dimensions 35 mm × 60 mm or 63 mm × 26 mm × 32 mm; thickness 0.45–0.47 mm GI

GRADE & SPECIFICATION

Cold-formed light-gauge GI (hot-dip galvanised) or Zincalume Z- or multi-truss section; thickness typically 0.45–0.47 mm; designed for direct fixing of roof tiles or corrugated sheets across C-purlin spans.

TARIFF & TAX — PDK 2025

HS CODE (AHTN) 7210619200 (MEDIUM CONFIDENCE)

OFFICIAL DESCRIPTION Other, corrugated (flat-rolled steel, zinc-coated — Z-purlin/batten from same material group)

IMPORT DUTY (MFN) 15%

SST 5%

Sourced from PDK 2025 (Customs Duties Order 2025). The import duty shown is the MFN / general rate — preferential rates under FTAs (ATIGA, ACFTA, etc.) are typically lower or zero. SST per the PDK 2025 schedule (a value like 10%/0% means standard/exempt variants). Indicative only — confirm the applicable rate and tax treatment with your licensed customs/tax agent before relying on it. Spotted an error? hello@ttkbuildingmaterials.com
