Name: Waler Plate / Soldier (Formwork Waling)
Brand: ttkbuildingmaterials.com Product Index
Availability: InStock

WHAT IT IS

Waler plate (soldier) is a horizontal or vertical steel C-channel clamped to the back of wall and column formwork panels at tie rod positions. Used in pairs (double waler), the channels distribute the concentrated tie rod load across multiple panel widths, preventing point failure of the form face. Standard profiles: 100 mm × 50 mm or 150 mm × 65 mm channel; available in lengths 1.5 m to 6.0 m. Steel grade S235 or S355 to BS EN 10025; spacing and span designed per BS 5975:2019 waling tables. Critical in retaining structure, basement wall, and bridge abutment formwork in Malaysia. HS 7308909900 · import duty 15% · SST 0%.

UNIT OF MEASURE

PIECE (PRIMARY) M SET

Typical pack size: Steel channel (C-channel or double-C): 100 mm × 50 mm or 150 mm × 65 mm; lengths 1.5 m, 2.0 m, 2.4 m, 3.0 m, 4.0 m, 6.0 m

GRADE & SPECIFICATION

Steel C-channel or U-channel to BS EN 10025 grade S235/S355. Used in pairs (double-waler) at each tie rod position. Bending resistance distributes tie rod point load across multiple form panels. Span and spacing per BS 5975:2019 design tables.

CLASSIFICATION

UNSPSC 30191802

CIDB CATEGORY Formwork/Falsework — Tie Rods & Accessories (under CIS 23:2023)

UNSPSC codes are issued by the United Nations Global Marketplace (UNGM). CIDB categories are defined by Malaysia's Construction Industry Development Board. These codes are informational — use them to verify, not replace, procurement classification.

TARIFF & TAX — PDK 2025

HS CODE (AHTN) 7308909900 (MEDIUM CONFIDENCE)

OFFICIAL DESCRIPTION Other

IMPORT DUTY (MFN) 15%

SST 0%

Sourced from PDK 2025 (Customs Duties Order 2025). The import duty shown is the MFN / general rate — preferential rates under FTAs (ATIGA, ACFTA, etc.) are typically lower or zero. SST per the PDK 2025 schedule (a value like 10%/0% means standard/exempt variants). Indicative only — confirm the applicable rate and tax treatment with your licensed customs/tax agent before relying on it. Spotted an error? hello@ttkbuildingmaterials.com
